This product is composed of 3.2V 100AH new lithium iron phosphate battery by 16S 1P mode. The battery pack adopts scientific internal structure design, advanced BMS system, industry-leading production technology, high specific energy, long life, safe and reliable. With the characteristics of wide temperature range, it is an ideal green energy storage power product.
Compatible, can be connected to different types of loads within the voltage range.
Support up to 15 modules in parallel.
Wall brackets can meet the installation and use of different places.
BMS built inside,over-voltage,over-load, and over-temperature protection. Etc.
LCD monitor the energy storage power data and operating status.
High-quality LiFePO4 battery, safety, deep cycle and long lifespan.
Product round edge be safer. avoid accident collision.
| Battery Model | LS-W5120 |
| Battery Type | LiFePO4 |
| Battery Rated Voltage(V) | 51.2V |
| Battery Rated Capacity(0.2C) | 100Ah |
| Energy(Wh) | 5120 |
| Size(L*W*H)mm | 600*500*165 |
| Weight(kg) | 48.35 |
| Operating Voltage Range(V) | 40-58.4V |
| Recommended charging current(A) | 20A |
| Maximum Continuous Charging Current (A) | 100A |
| Maximum Continuous Discharge Current(A) | 100A |
| Peak Discharge Current (A) | 320A(3S) |
| Internal Resistance(m&) | 40 mΩ |
| Storage Temperature | 10℃~50℃ |
| Storage Humidity | 10%~90% RH |
| Shipping Voltage | 51V～52V |
| Charging Temperature | 0~55℃ |
| Discharge Temperature | -20~55℃ |
| Cooling Mode | natural cooling |
| Waterproof Level | IP65 |
| Battery Cycle Life | 6000 times (standard charge and discharge) |
| Standard Environmental condition | Temperature: 23±5℃ |
| Humidity: 45-75%RH | |
| Atmospheric Pressure: 86-106 KPA |
