The battery pack adopts a scientific internal structure design, advanced BMS system, industry-leading production technology, high specific energy, long life, safety, and reliability. It has the characteristics of a wide temperature range and is an ideal green energy storage power product.
Standard 3U and 4U case, good applicability
With RS485 communication, you can monitor the battery status at any time and set protection parameters such as charge and discharge according to customer's requirements.
Add the current limiting module, support multiple batteries for parallel use, expand the battery capacity, and meet the high energy demand of customers.
Warning functions such as overcharge,over-discharge, over current, high and low temperatures can greatly reduce the potential safety hazard.
Automatic collection of battery single series voltage, pressure difference up to 30MV(can be set), automatic start equalization function.
| Battery Model | LS-RM5120 |
| Battery Type | LiFePO4 |
| Battery Rated Voltage (V) | 51.2V |
| Battery Rated Capacity (0.2C) | 100Ah |
| Energy(Wh) | 5120 |
| Size(L*W*H)mm | 460(including lug 500)*475*155 |
| Weight(kg) | ≤46 |
| Operating Voltage Range (V) | 40-58.4V |
| Recommended charging current(A) | 20A |
| Maximum Continuous Charging Current(A) | 100A |
| Maximum Continuous Discharge Current(A) | 100A |
| Peak Discharge Current(A) | 320A(3S) |
| Internal Resistance (mΩ) | 40mΩ |
| Storage Temperature | 10℃~35℃ |
| Storage Humidity | 10%~90%RH |
| Shipping Voltage | 51V～52V |
| Charging Temperature | 0~55℃ |
| Discharge Temperature | -20~55℃ |
| Cooling Mode | natural cooling |
| Battery Cycle Life | 6000 times (standard charge and discharge) |
| Standard Environmental condition | Temperature:23±5℃ |
| Humidity:45-75%RH | |
| Atmospheric Pressure:86-106 KPA |
